350/400/450/500/550/600/650/700mA 20W Constant Current DALI-2 Driver DT8 EUP20D-2HMC-0
EUP20D-2HMC-0 is a 20W AC/DC constant current mode output LED driver featuring the multiple
levels selectable by DIP switch and complies with DALI standard protocol IEC 62386-209.
EUP20D-2HMC-0 can be connected to DALI main controller or Touch DIM to a chieve a smooth dimming effect.
Short Description:
Item No.:EUP20D-2HMC-0
Input Voltage:220-240VAC
Output Power:20W
Features
1. Two channel output, output current level selectable by DIP S.W.
2. Meet DALI Protocol IEC 62386-209
3. Support Touch-DIM function
4. High efficiency up to 86 %
5. Built-in active PFC function
6. Dimming effect smooth, no flicker
7. Protections: Short circuit, over load, over voltage
8. Suitable for indoor LED lighting application, such as down light, panel light, and so on
Package Included:
1 Piece of Euchips EUP20D-2HMC-0 20W DALI CC Led Driver 2ch DT8 350-700mA
1 Piece of User's Manual
CE and RoHS approved
